Zoom200W Wind Turbine, 200Watt Angel Wind Turbine Generator
200W Angel Wind Turbine Introduce:
200W Angel Wind Turbine with magnetic saturation patent technology. Its easy to install, and generator is small volume only weight of 7-8.5kg, this weight is half of other same power product .200W Angel Wind Turbine low start up wind speed,only 2m/s, and low rated wind speed design only 7–8m/s.
200W Angel Wind Turbine Feature:
1.2m/s start-up wind speed with Low–torque starting technique (0.7n/m)
2.Light generator about 7-8.5kgs, easy to install
3.The blade casted into molding at one time with balance up to 99%
4.The tail processed with reinforced rib
5.Matched controller with PWM charging, electronic and manual brake, and LCD display
6.Automatic yaw and manual yaw,optional
7.It can supply about 50kwh per month under the condition that average wind speed is 12m/s per day ,valid wind hours is 210h per month.
200W Angel Wind Turbine power curve:
200W Angel Wind Turbine Specification:
| Model | Angel-200 |
| rated power (W) | 200W |
| rated voltage (V) | 12V,24V |
| rotor diameter (m) | 1.44 |
| start-up wind speed(m/s) | 2 |
| rated wind speed(m/s) | 8 |
| security wind speed (m/s) | 35 |
| yawing type | Mechanism |
| rated rotating rate (r/m) | 450 |
| generator work way | magnetic saturation |
| generator material | casted iron |
| blade material | Engineering plastic |
| blade quantity | 3&5 |
| tower Height (m) | 6 |
| tower Diameter (mm) | 89 |
| suggested battery capacity | 12V150AH 2pcs |
| Matched inverter type | sine wave |
