400W Wind Turbine, 400Watt Angel Wind Turbine Generator

Posted by admin in News

400W Wind Turbine, 400Watt Angel Wind Turbine



400W Angel Wind Turbine Introduce:
400W Angel Wind Turbine with magnetic saturation patent technology. Its easy to install, and generator is small volume only weight of 7-8.5kg, this weight is half of other same power product .400W Angel Wind Turbine low start up wind speed,only 2m/s, and low rated wind speed design only 7–8m/s.


400W Angel Wind Turbine Feature:
1.2m/s start-up wind speed with Low–torque starting technique (0.7n/m)
2.Light generator about 7-8.5kgs, easy to install
3.The blade casted into molding at one time with balance up to 99%
4.The tail processed with reinforced rib
5.Matched controller with PWM charging, electronic and manual brake, and LCD display
6.Automatic yaw and manual yaw,optional
7.It can supply about 50kwh per month under the condition that average wind speed is 12m/s per day ,valid wind hours is 210h per month.


400W Angel Wind Turbine power curve:

400W Wind Turbine power curve



400W Wind Turbine Specification:

Model Angel-400
rated power (W) 400W
rated voltage (V) 12V,24V
rotor diameter (m) 1.44
start-up wind speed(m/s) 2
rated wind speed(m/s) 10
security wind speed (m/s) 35
yawing type Mechanism
rated rotating rate (r/m) 450
generator work way magnetic saturation
generator material casted iron
blade material Engineering plastic
blade quantity 3&5
tower Height (m) 6
tower Diameter (mm) 89
suggested battery capacity 12V150AH 2pcs
Matched inverter type sine wave

400Watt Angel Wind Turbine Generator
